Baker HRC Cartridge Filter Parts
Home - > Parts Diagrams -> Baker Hydro-> Filters -> Baker Hydro HRC Filter
Baker Hydro HRC Cartridge Filter Parts Diagram
Baker Models: HRC
Baker Hyrdo HRC Sand Filter Parts List
| Key | Model | Description | Product ID | Buy Me | 1 | 30B3000 | Gauge 0-50 PSI | FI-02460 |
|---|---|---|---|---|
| 2 | 15B0299 | V-Band Lid Assembly, 1984 - | FI-23304 | |
| 3 | 00B8083 | Clamp Assembly, V-Band | FI-23306 | |
| 4 | 15B0074 | Air Relief Screen | FI-23308 | |
| 5 | APCO2068 | Gasket, V-Band Lid, Generic | OR-0215 | |
| -- | 00B7013 | Gasket, V-Band Lid, OEM | FI-23307 | |
| 6 | 15B0043 | Dome Distributor | FI-23310 | |
| 7 | 15B0020 | 24 Inch Distributor Pipe Assembly | FI-23312 | |
| -- | 15B0024 | 30 Inch Distributor Pipe Assembly | FI-23314 | |
| -- | 15B0177 | 18 Inch Distributor Pipe Assembly | FI-23315 | |
| -- | 15B0226 | 36 Inch Distributor Pipe Assembly | FI-23316 | |
| -- | 15B0101 | 24 Inch Vent Tube Assembly, 17.5 Inches Long | FI-23318 | |
| -- | 15B0102 | 30 Inch Vent Tube Assembly, 19.5 Inches Long | FI-23319 | |
| -- | 15B0183 | 18 Inch Vent Tube Assembly, 16.5 Inches Long | FI-23321 | |
| -- | 15B0232 | 36 Inch Vent Tube Assembly, 22.5 Inches Long | FI-23322 | |
| 10 | 15B0319 | Winterdrain Screen | FI-23324 | |
| 11 | 15B0124 | 8.5 InchThreaded Lateral HRV 30 Inch and 36 Inch | FI-23326 | |
| -- | 15B0125 | 5.5 Inch Threaded Lateral HRV 18 Inch and 24 Inch | FI-23327 | |
| 12 | 15Q0312 | Base HRV 24 Inch, 25 Inch | FI-23328 | |
| -- | 15Q0313 | Base HRV 30 Inch, 31 Inch | FI-23329 | |
| -- | 15Q0314 | Base HRV 36 Inch | ||
| -- | 15Q0315 | Base HRV 18 Inch, 21 Inch | ||
| -- | 16B0306 | 24", 25" Winterdrain Assy | ||
| -- | 16B0307 | 30", 31" Winterdrain Assy | ||
| -- | 16B0308 | 36" Winterdrain Assy | ||
| 14 | 88B3043 | Winterdrain Cap, 1" | ||
| 15 | 31B0077 | Bulkhead Union Adaptor w/o Gasket | FI-23336 | |
| 16 | 00B7027 | Gasket, Bulkhead Adaptor, OEM | FI-23337 | |
| -- | -- | Gasket, Bulkhead Adaptor, Generic | OR-0041 | |
| -- | -- | Bulkhead Nut See 21 | ||
| 31B9033 | Keyed Spacer HRV 18 Inch and 24 Inch | |||
| -- | 31B9034 | Keyed Spacer HRV 30 Inch and 36 Inch | ||
| 19 | 31B9032 | Bulkhead Fitting | ||
| 20 | 31B9035 | Gasket, Bulkhead HRV 18 Inch and 24 Inch | ||
| -- | 31B9036 | Gasket, Bulkhead HRV 30 Inch and 36 Inch | 21 | 31B9031 | Bulkhead Assy, Includes 17 |
| 22-- | 15D0170 | Dual Collector Assy HRV 30 Inch Less Laterals | ||
| -- | 15D0227 | Dual Collector Assy HRV 36 Inch Less Laterals | ||
| Terms: | NLA = No Longer Availble. | |||
| DS = Drop Shipped, Cannot be combined with any other Items. | ||||
| OS=Cannot Ship UPS & Cannot be combined with other items | ||||
Notice / Important: When adding items to the shopping cart from this page, please make sure that the item added is the same as listed on this page. Occasionally part numbers will change and will not be reflected on this page
